This high-performance Layer 2 managed switch features a compact and durable design ideal for desktop, wall, DIN rail, or magnetic mounting. With a robust switching capacity of 60 Gbps and non-blocking throughput of 30 Gbps, it efficiently supports high-speed networking for demanding environments.
Key Features:
-
Port Configuration:
-
8 × 2.5 GbE RJ45 ports (10M/100M/1G/2.5G)
-
1 × 10 GbE RJ45 port (10M to 10G)
-
1 × 10G SFP+ port
-
-
Layer 2 Capabilities:
-
VLAN support (up to 256)
-
STP & RSTP
-
Jumbo frame support
-
Port mirroring, isolation, and loop protection
-
Storm, multicast, and broadcast rate limiting
-
-
Hardware & Power:
-
Power input via USB Type-C (5V DC, 3A) or PoE+ (44–57V)
-
Max. power consumption: 14W
-
External 15W AC/DC power supply included
-
-
Compact & Lightweight:
-
Dimensions: 212.9 × 76 × 33.5 mm (8.4 × 3 × 1.3″)
-
Weight: 395 g (0.87 lb)
-
Durable polycarbonate enclosure
-
